ARTEOTOMY™ (OP1)

Nowhere has the budget-restricted dentist been more hard-pressed to find affordable equipment than in the realm of oral surgery. Hygiene devices have had less-expensive variants for many years, and though they were often regrettably of poorer quality, they had a simple function and were generally serviceable at the level they were intended. Not so with oral surgery devices, which require a level of technology, craftmanship, safety and know-how to manufacture, which essentially made them impossible to produce at competitive prices.

Until now.

Bonart Co. Ltd. is proud to present the ARTeotomy™ OP1, quite possibly the most powerful, safe, and affordable surgical device on the market. Previously only available as technology in private-label units (where it has been critically lauded for over a decade), it is now presented in a stand-alone package, straight from Bonart™, available to all.

Sinus lifts, bone surgery, orthodontics, endodontics…it’s all possible with the OP1, and its compatibility with every major brand of surgical tips (as well as Bonart™’s own trusted brand) is unmatched.

Featuring a micro-processor-controlled hand piece for instantaneous frequency adjustment, a cordless, programmable Bluetooth footswitch, and a variable, modulated driving signal for precise and instantaneous power adjustment, the ARTeotomy™ OP1 is a huge leap forward.

SPECIAL FEATURES

  • Touch screen interface
  • Wireless Bluetooth foot control
  • Auto gain closed loop control circuit
  • OP1 Main Unit
  • Hand piece
  • Foot switch
  • Stainless steel container for holding accessories during sterilization
  • Torque controlled metal wrench designed to prevent tips from breaking during installation
  • Assorted tip set with tip holder

Included accessories may vary per region

  • Power Supply:
    110V-115V±5% ~50/60Hz 30VA
    220-230V ±5% ~50/60Hz 30VA
  • Working Frequency: 26KHz ~ 32KHz
  • Delivery Rate of Pump: Max. 100 ml per minute
  • Device dimension:
    20cm(L) x 36cm (W) x 11cm (H)
    7.87 inches x 14.17 inches x 4.33 inches
  • Irrigation bag stand length: 45 cm / 17.72 inches
  • Hand piece and cable assembly length: 250 cm / 8.20 ft.
